4610-6250

10 Pos 2.54mm RA Header, Male Pin, IDT, 1A, Gold

10-position, 2-row shrouded header with a 2.54mm pitch, designed for right-angle, free-hanging cable mounting. Features male pin contacts made of copper alloy with gold plating, rated for 1A current. The grey housing is constructed from lead-free materials and operates within a temperature range of -55°C to 105°C. Termination is via Insulation Displacement Connector (IDT) for discrete or ribbon wire gauges from 26 to 28 AWG.

Current Rating1A

MountingFree Hanging

Quick Jump:

Technical Specifications

3M 4610-6250 technical specifications.

General

Color	Grey
Contact Gender	Male
Contact Material	Copper Alloy, Copper
Contact Plating	Gold
Contact Type	Male Pin
Current Rating	1A
Depth	8.4mm
Gender	Male
Housing Color	Grey
Lead Free	Lead Free
Length	38.1mm
Max Current Rating	1A
Max Operating Temperature	105°C
Min Operating Temperature	-55°C
Mount	Free Hanging
Number of Contacts	10
Number of Positions	10
Number of Rows	2
Orientation	Right Angle
Package Quantity	100
Packaging	Bulk
Pitch	2.54mm
Reach SVHC Compliant	No
RoHS Compliant	Yes
Row Spacing	2.54mm
Series	4600
Termination	IDT
Weight	1.8lb
Width	8.4mm
Wire Gauge (Max)	28AWG
Wire Gauge (Min)	26AWG
Wire/Cable Type	Discrete, Ribbon
