8250-6005

Datasheet

50 Pos Male D-Sub Connector, Right Angle, IDC, 1A, 350V

8250-6005

Name: 8250-6005 3M
Brand: 3M
SKU: 8250-6005

50 Pos Male D-Sub Connector, Right Angle, IDC, 1A, 350V

Standard D-Subminiature Connector, Male, 50 Positions, 3 Rows, 2.74mm Pitch. Features IDC termination, right-angle orientation, and a steel shell with nickel/gold plating. Rated for 1A current and 350V AC/DC, with a -55°C to 105°C operating temperature range. UL approved and RoHS compliant, with a UL94 V-0 flammability rating.

PackageMetal

Current Rating1A

MountingPanel, Cable

Quick Jump:

Technical Specifications

3M 8250-6005 technical specifications.

General

Approvals	UL
Body Material	Metal
Package/Case	Metal
Color	Grey
Contact Current Rating	1A
Contact Material	Copper Alloy, Copper, Gold
Contact Plating	Nickel, Gold
Contact Type	Signal
Current Rating	1A
Depth	24.49mm
Dielectric Material	PBT
Flammability Rating	UL94 V-0
Gender	Male
Housing Color	Grey
Insulation Material	Polyester
Lead Free	Lead Free
Lead Pitch	2.74mm
Length	70.9mm
Material	Steel
Mating Cycles	200
Max Current Rating	1A
Max Operating Temperature	105°C
Min Operating Temperature	-55°C
Mount	Panel, Cable
Number of Contacts	50
Number of Ports	1
Number of Positions	50
Number of Rows	3
Orientation	Right Angle
Package Quantity	200
Packaging	Tray
Pitch	2.74mm
Plating	Steel
Radiation Hardening	No
Reach SVHC Compliant	No
RoHS Compliant	Yes
Series	8250
Shell Material	Steel
Shell Size	D
Termination	IDT
Voltage Rating (AC)	350V
DC Rated Voltage	350V
Weight	1lb
Width	15.2mm
