The TO-220 Anodized Aluminium Heat Sink is a passive component with a rectangular shape, measuring 24.89mm in length and width. It has a natural thermal resistance of 16.8°C/W and a thermal resistance of 6°C/W when subjected to forced air flow at 100 LFM. The heat sink is made of anodized aluminium and is available in a package quantity of 1000 units. It is compliant with RoHS regulations and is suitable for clip mount and through hole PCB mounting.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Aavid 579302B00000G datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | TO-220 |
| Color | Black |
| Depth | 19.05mm |
| Finish | Anodized |
| Height | 11.18mm |
| Height Off Base | 0.44inch |
| Lead Free | Lead Free |
| Length | 24.89mm |
| Material | Aluminium, Anodized |
| Mount | Clip, Through Hole, PCB |
| Natural Thermal Resistance | 16.8°C/W |
| Package Cooled | TO-220 |
| Package Quantity | 1000 |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Shape | Rectangular |
| Thermal Resistance @ Forced Air Flow (100 LFM) | 6°C/W |
| Type | Passive |
| Width | 24.89mm |
| RoHS | Compliant |
