PackageAluminum
Voltage300V
Voltage Rating300V
MountingCable
Quick Jump:
Technical Specifications
Alpha Wire 5273C-SL005 technical specifications.
General
Approvals
UL, CSA, CE
Package/Case
Aluminum
Color
Grey
Conductor Material
Copper
Insulation Diameter
0.252inch
Insulation Material
PVC
Insulation Thickness
0.032inch
Jacket Material
PVC
Length
100foot
Max Operating Temperature
105°C
Min Operating Temperature
-35°C
Mount
Cable
Number of Conductors
6
Number of Pairs
3
Outside Diameter
6.35mm
Package Quantity
1
Reach SVHC Compliant
No
Series
Xtra-Guard® 1
Shielding
Shielded
Stranding
7 x 32
Voltage
300V
Voltage Rating
300V
Weight
3.66lb
Wire/Cable Gauge
24AWG
Wire/Cable Type
Multi-Pair
Compliance
RoHS
Compliant
Datasheet
Alpha Wire 5273C-SL005 Datasheet
Download the complete datasheet for Alpha Wire 5273C-SL005 to view detailed technical specifications.
