Right angle FFC/FPC board connector, receptacle gender, featuring 4 contacts and 1mm pitch. This surface mount component offers a 1A current rating and 100V voltage rating. Constructed with bronze contacts and tin plating, it operates within a -55°C to 105°C temperature range and boasts a UL94 V-0 flammability rating. The black housing is designed for straight wire/cable types and is lead-free.
Voltage Rating100V
Current Rating1A
MountingSurface Mount
Quick Jump:
Technical Specifications
Amphenol HFW4R-1STE9LF technical specifications.
General
Contact Location
Bottom
Contact Material
Bronze
Contact Plating
Tin
Current Rating
1A
Depth
5.5mm
Flammability Rating
UL94 V-0
Gender
Receptacle
Housing Color
Black
Lead Free
Lead Free
Length
6.6mm
Max Operating Temperature
105°C
Min Operating Temperature
-55°C
Max Voltage Rating (AC)
100V
Max Voltage Rating (DC)
100V
Mount
Surface Mount
Number of Contacts
4
Number of Positions
4
Number of Rows
1
Orientation
Right Angle
Package Quantity
500
Packaging
Tape and Reel
Pitch
1mm
Radiation Hardening
No
Reach SVHC Compliant
No
Series
HFW-R
Termination
Solder
Voltage Rating
100V
Wire/Cable Type
Straight
Compliance
RoHS
Compliant
Datasheet
Amphenol HFW4R-1STE9LF Datasheet
Download the complete datasheet for Amphenol HFW4R-1STE9LF to view detailed technical specifications.
