MIL-DTL-26482 Series I, PT circular connector, receptacle gender, featuring 6 contacts with gold-plated copper alloy sockets. This straight, panel-mount connector boasts a 7.5A current rating and 600V voltage rating, with a temperature range of -55°C to 125°C. The aluminum alloy shell is finished with cadmium and chromate plating, offering environment-sealed and resistant ratings. Termination is via solder for wire gauges 20-24AWG.
Voltage Rating600V
Current Rating7.5A
MountingPanel, Flanges, Wall
Quick Jump:
Technical Specifications
Amphenol PT00E-10-6S technical specifications.
General
| Approvals | UL |
| Body Material | Aluminium |
| Body Plating | Cadmium |
| Color | Green |
| Contact Finish - Mating | GOLD |
| Contact Gender | Female |
| Contact Material | Copper Alloy |
| Contact Plating | Gold |
| Contact Type | Socket |
| Current Rating | 7.5A |
| Gender | Receptacle |
| Max Operating Temperature | 125°C |
| Military Standard | MIL-DTL-26482 |
| Min Operating Temperature | -55°C |
| Mount | Panel, Flanges, Wall |
| Number of Contacts | 6 |
| Number of Positions | 6 |
| Orientation | Straight |
| Packaging | Bulk |
| Plating | Cadmium, Chromate |
| Radiation Hardening | No |
| Ratings | Environment Sealed, Environment Resistant |
| Reach SVHC Compliant | No |
| RoHS Compliant | No |
| Series | MIL-DTL-26482 Series I, PT |
| Shell Finish | Cadmium |
| Shell Material | Aluminium |
| Shell Size | 10 |
| Shielding | Unshielded |
| Termination | Solder |
| Voltage Rating | 600V |
| Voltage Rating (AC) | 600V |
| Wire Gauge (Max) | 24AWG |
| Wire Gauge (Min) | 20AWG |
Compliance
| RoHS | Not CompliantNo |
Datasheet
Amphenol PT00E-10-6S Datasheet
Download the complete datasheet for Amphenol PT00E-10-6S to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
