Shielded, waterproof, and dust-tight modular Ethernet connector for telecom and datacom applications. Features a single port with IDC termination for 24AWG round cable. Offers a 1.2A current rating and 100V voltage rating, with gold-plated bronze contacts. Operates across a -40°C to 85°C temperature range and meets UL94 V-0 flammability standards. RoHS compliant and packaged in bulk.
Voltage Rating100V
Current Rating1.2A
MountingCable
Quick Jump:
Technical Specifications
Conec 17-10001 technical specifications.
General
Color
Clear
Contact Material
Bronze
Contact Plating
Gold
Current Rating
1.2A
Flammability Rating
UL94 V-0
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Mount
Cable
Number of Ports
1
Package Quantity
100
Packaging
Bulk
Ratings
IP67, Waterproof, Dust Tight
RoHS Compliant
Yes
Shielding
Shielded
Termination
IDC
Voltage Rating
100V
Wire/Cable Gauge
24AWG
Wire/Cable Type
Round
Compliance
RoHS
Compliant
Datasheet
Conec 17-10001 Datasheet
Download the complete datasheet for Conec 17-10001 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
