Technical Specifications
Crydom D2D07 technical specifications.
General
Control Voltage
32V
Depth
58.4mm
Height
23mm
Input Current
28mA
Input Type
DC
Isolation Voltage
2.5kV
Isolation Voltage-Max
2.5kV
Lead Free
Lead Free
Length
45.7mm
Load Current
7A
Max Input Current
28mA
Max Operating Temperature
80°C
Min Operating Temperature
-20°C
Max Output Current
7A
Max Output Voltage
200V
Max Supply Voltage (DC)
200V
Min Supply Voltage (DC)
0V
Max Voltage Rating (DC)
200V
Mount
Surface Mount, Screw
Operating Supply Voltage
200V
Output Current
7A
Output Voltage
200V
Radiation Hardening
No
Reach SVHC Compliant
No
RoHS Compliant
Yes
Throw Configuration
SPST
Compliance
RoHS
Compliant
Datasheet
Crydom D2D07 Datasheet
Download the complete datasheet for Crydom D2D07 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
