9Mb ZBT SRAM, 256K x 36, featuring 3.5ns access time and 166MHz maximum frequency. This CMOS, PBGA119 packaged device offers a parallel interface, 18-bit address bus, and 4 ports. Operating at 3.3V, it supports surface mount installation and is supplied in tape and reel packaging.
Frequency166MHz
PackageBGA
Current180mA
MountingSurface Mount
Quick Jump:
Technical Specifications
Cypress CY7C1354C-166BGCT technical specifications.
General
Access Time
3.5ns
Address Bus Width
18b
Package/Case
BGA
Density
9Mb
Frequency
166MHz
Interface
Parallel
Lead Free
Contains Lead
Max Frequency
166MHz
Max Operating Temperature
70°C
Min Operating Temperature
0°C
Max Supply Voltage
3.6V
Memory Size
9Mb
Memory Type
SDR, , Volatile, SRAM
Min Supply Voltage
3.135V
Mount
Surface Mount
Number of Ports
4
Number of Words
256000
Operating Supply Voltage
3.3V
Package Quantity
500
Packaging
Tape and Reel
Radiation Hardening
No
RoHS Compliant
No
Series
NoBL™
Supply Current
180mA
Sync/Async
Synchronous
Word Size
36b
Compliance
RoHS
Not CompliantNo
Datasheet
Cypress CY7C1354C-166BGCT Datasheet
Download the complete datasheet for Cypress CY7C1354C-166BGCT to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
