9Mb ZBT SRAM, featuring 512K x 18 configuration and 3.5ns access time. This synchronous, volatile memory operates at 166MHz with a parallel interface. Packaged in a 119-ball PBGA for surface mounting, it supports a 3.3V operating supply voltage.
Frequency166MHz
PackageBGA
Current180mA
MountingSurface Mount
Quick Jump:
Technical Specifications
Cypress CY7C1356C-166BGC technical specifications.
General
Access Time
3.5ns
Address Bus Width
19b
Package/Case
BGA
Density
9Mb
Frequency
166MHz
Interface
Parallel
Max Frequency
166MHz
Max Operating Temperature
70°C
Max Supply Voltage
3.6V
Memory Size
9Mb
Memory Type
SDR, , Volatile, SRAM
Min Operating Temperature
0°C
Min Supply Voltage
3.135V
Mount
Surface Mount
Number of Ports
2
Number of Words
512000
Operating Supply Voltage
3.3V
Package Quantity
84
Packaging
Tray
Radiation Hardening
No
RoHS Compliant
No
Series
NoBL™
Supply Current
180mA
Sync/Async
Synchronous
Word Size
18b
Compliance
RoHS
Not CompliantNo
Datasheet
Cypress CY7C1356C-166BGC Datasheet
Download the complete datasheet for Cypress CY7C1356C-166BGC to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
