9Mb Synchronous SRAM featuring 3.5ns access time and 166MHz maximum frequency. This volatile memory component offers an 18-bit address bus and 36-bit word size, with a 256,000 word count. Designed for surface mounting, it utilizes a BGA package and operates with a 3.3V supply voltage. The component supports a parallel interface and has four ports.
Frequency166MHz
PackageBGA
Current180mA
MountingSurface Mount
Quick Jump:
Technical Specifications
Cypress CY7C1366C-166BGCT technical specifications.
General
Access Time
3.5ns
Address Bus Width
18b
Package/Case
BGA
Density
9Mb
Frequency
166MHz
Interface
Parallel
Lead Free
Contains Lead
Max Frequency
166MHz
Max Operating Temperature
70°C
Max Supply Voltage
3.6V
Memory Size
9Mb
Memory Type
SDR, , Volatile, SRAM
Min Operating Temperature
0°C
Min Supply Voltage
3.135V
Mount
Surface Mount
Number of Ports
4
Number of Words
256000
Operating Supply Voltage
3.3V
Package Quantity
500
Packaging
Tape and Reel
Radiation Hardening
No
Supply Current
180mA
Sync/Async
Synchronous
Word Size
36b
Compliance
RoHS
Not CompliantNo
Datasheet
Cypress CY7C1366C-166BGCT Datasheet
Download the complete datasheet for Cypress CY7C1366C-166BGCT to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
