Five-pole female XLR panel mount connector featuring a durable metal body with chrome plating and a black finish. This connector utilizes silver-plated brass contacts for reliable signal transmission, offering a current rating of 7.5A and a voltage rating of 250V AC. Designed for solder termination, it operates within a temperature range of -30°C to 80°C and meets UL94 V-1 flammability standards.
PackageMetal
Voltage Rating250V
Current Rating7.5A
MountingPanel
Quick Jump:
Technical Specifications
Deltron 719-0500 technical specifications.
General
Body Material
Metal
Body Plating
Chrome
Package/Case
Metal
Color
Black
Contact Material
Brass
Contact Plating
Silver
Current Rating
7.5A
Flammability Rating
UL94 V-1
Gender
Female
Material
Chrome
Max Operating Temperature
80°C
Min Operating Temperature
-30°C
Mount
Panel
Number of Contacts
5
Number of Positions
5
Orientation
Vertical
Reach SVHC Compliant
Unknown
RMS Current (Irms)
7.5A
RoHS Compliant
No
Termination
Solder
Voltage Rating
250V
Voltage Rating (AC)
250V
Width
26mm
Working Voltage
250V
Compliance
RoHS
Not Compliant
Datasheet
Deltron 719-0500 Datasheet
Download the complete datasheet for Deltron 719-0500 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
