Everlight
4N35S(TA)
Transistor Output Optocoupler, 1-Element, 5000V Isolation, ROHS COMPLIANT, SURFACE MOUNT, DIP-6
PackageSMD/SMT
MountingSurface Mount
Quick Jump:
Technical Specifications
Everlight 4N35S(TA) technical specifications.
General
Approvals
UL
Package/Case
SMD/SMT
Collector Emitter Breakdown Voltage
80V
Collector Emitter Saturation Voltage
300mV
Collector-emitter Voltage-Max
300mV
Input Type
DC
Lead Free
Lead Free
Max Input Current
50mA
Max Operating Temperature
110°C
Min Operating Temperature
-55°C
Max Output Voltage
80V
Max Power Dissipation
200mW
Mount
Surface Mount
Number of Channels
1
Package Quantity
1000
Packaging
Tape and Reel
RoHS Compliant
Yes
Compliance
RoHS
Compliant
Datasheet
Everlight 4N35S(TA) Datasheet
Download the complete datasheet for Everlight 4N35S(TA) to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
