PackageRadial
MountingThrough Hole
Power100mW
Quick Jump:
Technical Specifications
Everlight IR333-A technical specifications.
General
Package/Case
Radial
Depth
5.9mm
Forward Current
50mA
Lead Free
Lead Free
Length
5.9mm
Lens Style
Diffused, Colored, Circular
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Mount
Through Hole
Number of Elements
1
Number of LEDs
1
Orientation
Top View
Packaging
Bulk
Power Dissipation
100mW
Reverse Voltage
5V
RoHS Compliant
Yes
Touchscreen
Infrared (IR)
Viewing Angle
20°
Wavelength
940nm
Compliance
RoHS
Compliant
Datasheet
Everlight IR333-A Datasheet
Download the complete datasheet for Everlight IR333-A to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
