Technical Specifications
Ftdi VNC1L-1A-REEL technical specifications.
General
Package/Case
LQFP
Data Bus Width
32b
Data Rate
480Mbps
Frequency
48MHz
Height
1.4mm
Interface
SPI, UART, USB
Lead Free
Lead Free
Length
7mm
Max Frequency
48MHz
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Max Supply Voltage
3.6V
Memory Size
64KB
Memory Type
FLASH,
Min Supply Voltage
3V
Mount
Surface Mount
Number of Channels
2
Number of Timers/Counters
1
Operating Supply Current
25mA
Operating Supply Voltage
3.3V
Package Quantity
2000
Packaging
Tape and Reel
Radiation Hardening
No
RAM Size
4KB
RoHS Compliant
Yes
Series
Vinculum
Weight
0.006409oz
Width
7mm
Compliance
RoHS
Compliant
Datasheet
Ftdi VNC1L-1A-REEL Datasheet
Download the complete datasheet for Ftdi VNC1L-1A-REEL to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
