12-position, 1-row shrouded header with straight, through-hole termination. Features male pin contacts made of brass and copper alloy with tin plating, rated for 3A current and 250V voltage. The black nylon housing has a 2mm pitch and 5mm height. Lead-free and RoHS compliant.
Voltage Rating250V
Current Rating3A
MountingThrough Hole
Quick Jump:
Technical Specifications
Hirose DF3A-12P-2DSA technical specifications.
General
Color
Black
Contact Gender
Male
Contact Material
Brass, Copper Alloy
Contact Plating
Tin
Contact Type
Male Pin
Current Rating
3A
Gender
Male
Height
5mm
Housing Color
Black
Insulation Material
Nylon
Lead Free
Lead Free
Length
26mm
Mount
Through Hole
Number of Contacts
12
Number of Positions
12
Number of Rows
1
Orientation
Straight
Package Quantity
100
Packaging
Bulk
Pitch
2mm
Radiation Hardening
No
Reach SVHC Compliant
No
RoHS Compliant
Yes
Series
DF3
Termination
Through Hole
Voltage Rating
250V
Compliance
RoHS
Compliant
Datasheet
Hirose DF3A-12P-2DSA Datasheet
Download the complete datasheet for Hirose DF3A-12P-2DSA to view detailed technical specifications.
