Technical Specifications
Kycon K42X-B25S/S-A4NJ technical specifications.
General
| Contact Material | Bronze |
| Contact Plating | Gold |
| Current Rating | 2A |
| Gender | Female to Female |
| Height | 31.6mm |
| Insulation | Insulated |
| Insulation Material | PBT |
| Max Operating Temperature | 105°C |
| Min Operating Temperature | -55°C |
| Mount | Through Hole |
| Number of Ports | 2 |
| Orientation | Right Angle |
| Package Quantity | 15 |
| Packaging | Tray |
| Pitch | 2.77mm |
| Plating | Tin |
| Radiation Hardening | No |
| RoHS Compliant | Yes |
| Series | K42X |
| Shell Material | Steel |
| Shell Size | B |
| Termination | Through Hole |
| Voltage Rating | 30V |
Compliance
| RoHS | Compliant |
Datasheet
Kycon K42X-B25S/S-A4NJ Datasheet
Download the complete datasheet for Kycon K42X-B25S/S-A4NJ to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
