Fast-acting electrical fuse with 80mA current rating and 250V AC/DC voltage rating. Features a ceramic body, axial termination, and through-hole mounting. Dimensions are 3.02mm diameter and 8.4mm length. Operating temperature range is -40°C to 125°C. RoHS compliant and supplied in an ammo pack.
PackageAxial
Current80mA
Storage3.02mm
Resistance8.19R
Quick Jump:
Technical Specifications
Littelfuse 0242.080UAT1 technical specifications.
General
Body Material
Ceramic
Package/Case
Axial
Color
Green
Current
80mA
Current Rating
80mA
DC Cold Resistance
8.19R
Diameter
3.02mm
Fuse Current
80mA
Lead Free
Lead Free
Length
8.4mm
Max Operating Temperature
125°C
Min Operating Temperature
-40°C
Mount
Through Hole
Package Quantity
500
Packaging
Ammo Pack
Radiation Hardening
No
Reach SVHC Compliant
Unknown
Resistance
8.19R
RoHS Compliant
Yes
Series
242
Size
3.02mm
Termination
Axial
Type
Electrical
Voltage Rating
250V
Voltage Rating (AC)
250V
DC Rated Voltage
250V
Working Voltage
250V
Compliance
RoHS
Compliant
Datasheet
Littelfuse 0242.080UAT1 Datasheet
Download the complete datasheet for Littelfuse 0242.080UAT1 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
