MS3V-T1R32.768kHz12.5pF+-20ppm

Crystal 32.768kHz, 20ppm, 2-Pin SMD, 5 x 1.4 x 1.4mm

Frequency32.768kHz

PackageSMD/SMT

MountingSurface Mount

Quick Jump:

Micro Crystal MS3V-T1R32.768kHz12.5pF+-20ppm technical specifications.

Package/Case

SMD/SMT

Frequency

32.768kHz

Frequency Tolerance

20ppm

Height

1.4mm

Length

5mm

Load Capacitance

12.5pF

Max Operating Temperature

85°C

Min Operating Temperature

-40°C

Mount

Surface Mount

Series Resistance

65kR

Width

1.4mm

RoHS

Compliant

No datasheet is available for this part.
