Frequency30MHz
PackagePLCC
MountingSurface Mount
Quick Jump:
Technical Specifications
Microchip AT80C32X2-SLSUL technical specifications.
General
Access Time
30us
Package/Case
PLCC
Core Architecture
80C51
Data Bus Width
8b
Frequency
30MHz
Interface
UART, USART
Lead Free
Lead Free
Max Frequency
30MHz
Max Operating Temperature
85°C
Max Supply Voltage
5.5V
Memory Type
ROMless,
Min Operating Temperature
-40°C
Min Supply Voltage
2.7V
Mount
Surface Mount
Number of I/Os
32
Number of Programmable I/O
32
Number of Timers/Counters
3
Oscillator Type
Internal
Package Quantity
972
Packaging
Rail/Tube
Peripherals
POR
RAM Size
256B
RoHS Compliant
Yes
Series
80C
Compliance
RoHS
Compliant
Datasheet
Microchip AT80C32X2-SLSUL Datasheet
Download the complete datasheet for Microchip AT80C32X2-SLSUL to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
