36-position, 4-row flexible flat cable/flexible printed circuit connector with a 4.19mm pitch and straight orientation. Features male contacts, a 4A current rating, and a maximum operating temperature of 105°C. This ZIF & LIF connector is panel, snap-in, and cable mountable with crimp termination. UL and CSA approved, it is RoHS compliant and constructed with a natural colored housing.
Current Rating4A
MountingPanel, Snap in, Cable
Quick Jump:
Technical Specifications
Molex 03-06-2361 technical specifications.
General
Approvals
UL, CSA
Color
Natural
Contact Gender
Male
Contact Type
Male or Female
Current Rating
4A
Depth
25.91mm
Flammability Rating
UL94 V-2
Gender
Male
Glow Wire Compliant
Non-compliant
Housing Color
Natural
Lead Free
Lead Free
Max Operating Temperature
105°C
Min Operating Temperature
-40°C
Mount
Panel, Snap in, Cable
Number of Contacts
36
Number of Positions
36
Number of Rows
4
Orientation
Straight
Package Quantity
25200
Packaging
Bulk
Pitch
4.19mm
Radiation Hardening
No
Reach SVHC Compliant
Unknown
RoHS Compliant
Yes
Row Spacing
0.145inch
Series
1772
Termination
Crimp
Compliance
RoHS
Compliant
Datasheet
Molex 03-06-2361 Datasheet
Download the complete datasheet for Molex 03-06-2361 to view detailed technical specifications.
