Voltage Rating250V
Current Rating2.5A
MountingThrough Hole
Quick Jump:
Technical Specifications
Molex 22-02-2095 technical specifications.
General
Contact Gender
Female
Contact Material
Brass
Contact Plating
Tin
Current Rating
2.5A
Gender
Female
Glow Wire Compliant
Non-compliant
Halogen Free
Low Halogen
Max Operating Temperature
75°C
Min Operating Temperature
0°C
Mount
Through Hole
Number of Circuits
9
Number of Contacts
9
Number of Positions
9
Number of Rows
1
Orientation
Straight
Package Quantity
1008
Packaging
Tray
Pitch
2.54mm
RoHS Compliant
Yes
Series
4455
Termination
Solder
Voltage Rating
250V
Compliance
RoHS
Compliant
Datasheet
Molex 22-02-2095 Datasheet
Download the complete datasheet for Molex 22-02-2095 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
