10-position, 2-row flexible flat cable (FFC) / flexible printed circuit (FPC) connector with ZIF/LIF technology. Features brass contacts with nickel plating, rated for 300V and 50A, accepting 6AWG wire. Insulation is phenolic with a UL94 V-0 flammability rating. Panel or chassis mountable with a straight orientation and 0.688-inch pitch. RoHS compliant and UL/CSA approved.
Voltage Rating300V
Current Rating50A
MountingPanel, Chassis
Quick Jump:
Technical Specifications
Molex 38280-0110 technical specifications.
General
Approvals
UL, CSA
Color
Blue, Black
Contact Material
Brass
Contact Plating
Nickel
Current Rating
50A
Flammability Rating
UL94 V-0
Housing Color
Black
Insulation Material
Phenolic
Lead Free
Lead Free
Mount
Panel, Chassis
Number of Circuits
10
Number of Contacts
10
Number of Poles
10
Number of Positions
10
Number of Rows
2
Number of Wire Entries
20
Orientation
Straight
Package Quantity
1
Packaging
Bulk
Pitch
0.688inch
Reach SVHC Compliant
Unknown
RoHS Compliant
Yes
Series
38280
Terminal Finish
Nickel
Terminal Material
Brass
Termination
Solder
Voltage Rating
300V
Wire/Cable Gauge
6AWG
Compliance
RoHS
Compliant
Datasheet
Molex 38280-0110 Datasheet
Download the complete datasheet for Molex 38280-0110 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
