6-position, single-row, straight flexible flat cable (FFC) / flexible printed circuit (FPC) connector with ZIF/LIF termination. Features brass contacts with tin/lead plating, a 9.53mm pitch, and a 25A current rating. Designed for panel mounting with a 300V voltage rating and accommodates wire gauges from 24AWG to 12AWG. The black housing is UL94 V-0 flammability rated, operating between 0°C and 110°C. RoHS compliant.
Voltage Rating300V
Current Rating25A
MountingPanel
Quick Jump:
Technical Specifications
Molex 38721-6706 technical specifications.
General
| Color | Black |
| Contact Material | Brass |
| Contact Plating | Tin, Lead |
| Current Rating | 25A |
| Flammability Rating | UL94 V-0 |
| Housing Color | Black |
| Lead Free | Lead Free |
| Max Operating Temperature | 110°C |
| Min Operating Temperature | 0°C |
| Mount | Panel |
| Number of Circuits | 6 |
| Number of Contacts | 6 |
| Number of Positions | 6 |
| Number of Rows | 1 |
| Orientation | Straight |
| Package Quantity | 25 |
| Packaging | Tray |
| Pitch | 9.53mm |
| Radiation Hardening | No |
| Reach SVHC Compliant | Unknown |
| RoHS Compliant | Yes |
| Series | 38721 |
| Termination | Solder |
| Voltage Rating | 300V |
| Wire Gauge (Max) | 12AWG |
| Wire Gauge (Min) | 24AWG |
| Wire/Cable Gauge | 12AWG |
Compliance
| RoHS | Compliant |
Datasheet
Molex 38721-6706 Datasheet
Download the complete datasheet for Molex 38721-6706 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
