8-circuit, 1-row, male right-angle PCB connector with a 1.1mm pitch. Features gold-plated stainless steel and copper alloy contacts, rated for 100V DC and 500mA current. This surface mount receptacle has a black insulator and is supplied on tape and reel. Operating temperature range is -20°C to 85°C.
Voltage Rating100V
Current Rating500mA
MountingSurface Mount
Quick Jump:
Technical Specifications
Molex 47334-0001 technical specifications.
General
| Contact Material | Stainless Steel, Copper Alloy, Copper |
| Contact Plating | Gold |
| Current Rating | 500mA |
| Depth | 15.2mm |
| Gender | Male |
| Length | 14mm |
| Max Operating Temperature | 85°C |
| Memory Type | FLASH, |
| Min Operating Temperature | -20°C |
| Mount | Surface Mount |
| Number of Circuits | 8 |
| Number of Contacts | 8 |
| Number of Rows | 1 |
| Orientation | Right Angle |
| Packaging | Tape and Reel |
| Pitch | 1.1mm |
| Plating | Tin |
| Radiation Hardening | No |
| Reach SVHC Compliant | Unknown |
| RoHS Compliant | Yes |
| Series | 47334 |
| Termination | SMD/SMT |
| Voltage Rating | 100V |
| DC Rated Voltage | 100V |
| Width | 1.88mm |
