Vertical male header connector with 4 positions and 4 circuits. Features brass contacts with tin plating and a blade pin contact type. Rated for 1.2A current and 250V voltage, operating between -40°C and 105°C. Through-hole mounting with solder termination. Black housing, lead-free and RoHS compliant.
Voltage Rating250V
Current Rating1.2A
MountingThrough Hole
Quick Jump:
Technical Specifications
Molex 90325-9004 technical specifications.
General
| Color | Black |
| Contact Material | Brass |
| Contact Plating | Tin |
| Contact Type | Blade Pin |
| Current Rating | 1.2A |
| Gender | Male |
| Glow Wire Compliant | Non-compliant |
| Housing Color | Black |
| Lead Free | Lead Free |
| Max Operating Temperature | 105°C |
| Min Operating Temperature | -40°C |
| Mount | Through Hole |
| Number of Circuits | 4 |
| Number of Contacts | 4 |
| Number of Positions | 4 |
| Number of Rows | 1 |
| Orientation | Vertical |
| Package Quantity | 1 |
| Packaging | Rail/Tube |
| Pitch | 1.27mm |
| Radiation Hardening | No |
| Reach SVHC Compliant | Unknown |
| RoHS Compliant | Yes |
| Series | Picoflex® PF-50 90325 |
| Termination | Solder |
| Voltage Rating | 250V |
Compliance
| RoHS | Compliant |
Datasheet
Molex 90325-9004 Datasheet
Download the complete datasheet for Molex 90325-9004 to view detailed technical specifications.
