MURATA

DMS-20PC-0-RL-C

Datasheet

Red 7-Seg Numeric LED Display, 0.48" H, 3.5 Char/Row, Panel Mount

Murata

DMS-20PC-0-RL-C

Name: DMS-20PC-0-RL-C Murata
Brand: Murata
SKU: DMS-20PC-0-RL-C

Red 7-Seg Numeric LED Display, 0.48" H, 3.5 Char/Row, Panel Mount

Red 0.48-inch height, 7-segment numeric LED display module with a 1.38 x 0.88-inch footprint. Features a 5V supply voltage range (4.75V to 5.25V) and operates at 7mA current. RoHS compliant, lead-free, and designed for panel mounting with PC pin terminations. This digital display offers a character height of 0.48 inches and a depth of 17.45mm.

MountingPanel

Quick Jump:

Technical Specifications

Murata DMS-20PC-0-RL-C technical specifications.

General

Depth	17.45mm
Display Type	Digital
Height	22mm
Lead Free	Lead Free
Length	12mm
Max Operating Temperature	60°C
Min Operating Temperature	0°C
Max Supply Voltage	5.25V
Min Supply Voltage	4.75V
Mount	Panel
Number Of Characters Per Row	3.5
Operating Supply Current	7mA
Package Quantity	12
Packaging	Bulk
Reach SVHC Compliant	No
RoHS Compliant	Yes
Series	DMS-20PC
Termination	PC Pin
Weight	0.025lb
Width	35mm
