PackagePLCC
MountingSurface Mount
Quick Jump:
Technical Specifications
Osram LAE6SF-BBCB-24-1 technical specifications.
General
Package/Case
PLCC
Color
Orange
Depth
3.4mm
Forward Current
70mA
Length
3mm
Lens Style
Round, Diffused, Colorless, Circular
Luminous Flux
10.11lm
Luminous Intensity
4500mcd
Max Operating Temperature
110°C
Min Operating Temperature
-40°C
Mount
Surface Mount
Number of Elements
1
Number of LEDs
1
Packaging
Tape and Reel
Radiation Hardening
No
Reverse Voltage
12V
RoHS Compliant
Yes
Series
Power TOPLED
Viewing Angle
120°
Wavelength
617nm
Compliance
RoHS
Compliant
Datasheet
Osram LAE6SF-BBCB-24-1 Datasheet
Download the complete datasheet for Osram LAE6SF-BBCB-24-1 to view detailed technical specifications.
