12-position, straight, male PCB terminal block with 5mm pitch. Features a 13.5A current rating and 400V voltage rating. Constructed with a green polyamide housing and tin-plated copper contacts. Designed for through-hole mounting with screw termination. UL94 V-0 flammability rating and UL, CSA, cULus, CB, EAC approvals.
Voltage300V
Current10A
Voltage Rating400V
Current Rating13.5A
Quick Jump:
Technical Specifications
Phoenix Contact 1729115 technical specifications.
General
| Approvals | UL, CSA, cULus, CB, EAC |
| Color | Green |
| Contact Material | Tin |
| Current | 10A |
| Current Rating | 13.5A |
| Flammability Rating | UL94 V-0 |
| Gender | Male |
| Height | 13.5mm |
| Housing Color | Green |
| Insulation Material | Nylon |
| Lead Free | Lead Free |
| Length | 8.1mm |
| Material | Polyamide |
| Max Current Rating | 13.5A |
| Mount | Through Hole |
| Number of Circuits | 12 |
| Number of Contacts | 12 |
| Number of Levels | 1 |
| Number of Poles | 12 |
| Number of Positions | 12 |
| Number of Positions Per Level | 12 |
| Number of Rows | 1 |
| Orientation | Straight |
| Packaging | Bulk |
| Pitch | 5mm |
| RoHS Compliant | Yes |
| Series | COMBICON MKDSN |
| Termination | Screw |
| Voltage | 300V |
| Voltage Rating | 400V |
| Weight | 0.417644oz |
| Width | 60mm |
| Wire Gauge (Max) | 30AWG |
| Wire Gauge (Min) | 14AWG |
Compliance
| RoHS | Compliant |
Datasheet
Phoenix Contact 1729115 Datasheet
Download the complete datasheet for Phoenix Contact 1729115 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
