Phoenix Contact
1736933
PCB connector, nominal current 12 A, rated voltage (III/2) 630 V, number of positions 12, pitch 7.62 mm,connection method Screw connection with tension sleeve, color black, contact surface Tin
Voltage Rating400V
Current Rating12A
MountingFree Hanging
Quick Jump:
Technical Specifications
Phoenix Contact 1736933 technical specifications.
General
| Color | Black |
| Contact Plating | Tin |
| Current Rating | 12A |
| Mount | Free Hanging |
| Number of Levels | 1 |
| Number of Positions | 12 |
| Number of Positions Per Level | 12 |
| Package Quantity | 50 |
| Packaging | Bulk |
| Pitch | 0.3inch |
| RoHS Compliant | Yes |
| Series | COMBICON GMSTB |
| Termination | Screw |
| Voltage Rating | 400V |
| Wire Gauge (Max) | 12AWG |
| Wire Gauge (Min) | 24AWG |
Compliance
| RoHS | Not Compliant |
