The 8-Port Ethernet Switch is a managed device with a data rate of 100Mbps and an operating supply voltage of 24V. It has an operating supply current of 220mA and is designed for DIN rail mounting. The switch is rated for a maximum operating temperature of 55°C and a minimum operating temperature of 0°C. It is approved for use in UL and EAC environments and is not Reach SVHC compliant.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Phoenix Contact 2832577 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Approvals | UL, EAC |
| Package/Case | 100 |
| Current Rating | 220mA |
| Data Rate | 100Mbps |
| Interface | Ethernet |
| Length | 115.3mm |
| Max Operating Temperature | 55°C |
| Min Operating Temperature | 0°C |
| Mount | DIN Rail |
| Number of Ports | 8 |
| Operating Supply Current | 220mA |
| Operating Supply Voltage | 24V |
| Package Quantity | 1 |
| Ratings | IP20 |
| Reach SVHC Compliant | No |
| DC Rated Voltage | 24V |
| Width | 135mm |
| RoHS | Compliant |
Download the complete datasheet for Phoenix Contact 2832577 to view detailed technical specifications.
