Voltage300V
Current20A
Voltage Rating400V
Current Rating20A
Quick Jump:
Technical Specifications
Phoenix Contact 3210172 technical specifications.
General
| Approvals | UL, CSA, VDE, CB, EAC |
| Color | Grey |
| Current | 20A |
| Current Rating | 20A |
| Flammability Rating | UL94 V-0 |
| Insulation Material | Nylon |
| Length | 84mm |
| Number of Levels | 1 |
| Number of Positions | 4 |
| Packaging | Bulk |
| RoHS Compliant | Yes |
| Series | CLIPLINE PT |
| Terminal Width | 5.2mm |
| Termination | Push-In |
| Voltage | 300V |
| Voltage Rating | 400V |
| Weight | 0.437397oz |
| Width | 5.2mm |
| Wire Gauge (Max) | 26AWG |
| Wire Gauge (Min) | 12AWG |
Compliance
| RoHS | Compliant |
Datasheet
Phoenix Contact 3210172 Datasheet
Download the complete datasheet for Phoenix Contact 3210172 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
