Technical Specifications
Phoenix Contact 3211822 technical specifications.
General
| Approvals | UL, CSA, VDE, CB, EAC |
| Color | Green, Yellow |
| Current Rating | 17.5A |
| Flammability Rating | UL94 V-0 |
| Height | 51mm |
| Insulation Material | Nylon |
| Lead Free | Lead Free |
| Length | 57.7mm |
| Number of Levels | 1 |
| Number of Positions | 2 |
| Number of Rows | 1 |
| Package Quantity | 50 |
| RoHS Compliant | Yes |
| Series | CLIPLINE PT |
| Terminal Width | 8.2mm |
| Termination | Push-In |
| Width | 8.2mm |
| Wire Gauge (Max) | 20AWG |
| Wire Gauge (Min) | 8AWG |
| Wire/Cable Gauge | 8AWG |
Compliance
| RoHS | Compliant |
Datasheet
Phoenix Contact 3211822 Datasheet
Download the complete datasheet for Phoenix Contact 3211822 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
