Voltage600V
Current60A
Voltage Rating600V
Current Rating70A
Quick Jump:
Technical Specifications
Phoenix Contact 3212120 technical specifications.
General
Approvals
UL, CSA, VDE, CB, EAC
Color
Grey
Current
60A
Current Rating
70A
Flammability Rating
UL94 V-0
Height
49.5mm
Insulation Material
Nylon
Length
67.7mm
Mount
Through Hole
Number of Levels
1
Number of Positions
2
Package Quantity
50
RoHS Compliant
Yes
Series
CLIPLINE PT
Terminal Width
10.2mm
Termination
Push-In
Voltage
600V
Voltage Rating
600V
Width
10.2mm
Wire Gauge (Max)
20AWG
Wire Gauge (Min)
6AWG
Wire/Cable Gauge
6AWG
Compliance
RoHS
Compliant
Datasheet
Phoenix Contact 3212120 Datasheet
Download the complete datasheet for Phoenix Contact 3212120 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
