Technical Specifications
Phoenix Contact 3212131 technical specifications.
General
Color
Green, Yellow
Current Rating
57A
Flammability Rating
UL94 V-0
Height
49.5mm
Insulation Material
Nylon
Length
67.7mm
Number of Levels
1
Number of Positions
2
Package Quantity
50
Pitch
3.5mm
RoHS Compliant
Yes
Series
CLIPLINE PT
Terminal Width
10.2mm
Weight
1.224712oz
Width
10.2mm
Wire Gauge (Max)
20AWG
Wire Gauge (Min)
6AWG
Wire/Cable Gauge
6AWG
Compliance
RoHS
Compliant
Datasheet
Phoenix Contact 3212131 Datasheet
Download the complete datasheet for Phoenix Contact 3212131 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
