SAMTEC

FHP-13-01-T-S

Datasheet

13 Pos 3.96mm Socket Strip Header, Straight, Thru-Hole Solder

Samtec

FHP-13-01-T-S

Name: FHP-13-01-T-S Samtec
Brand: Samtec
SKU: FHP-13-01-T-S

13 Pos 3.96mm Socket Strip Header, Straight, Thru-Hole Solder

13-position, single-row socket strip with a 3.96mm pitch. Features straight, through-hole mounting with solder termination. Contacts are female socket type, made from bronze and copper with tin plating for mating. The black polymer housing and insulation ensure a maximum operating temperature of 105°C.

MountingThrough Hole

Quick Jump:

Pricing & Availability

Distributor	Package Type	Min Qty	1+	25+	50+	100+	Stock	Action
Samtec	Tube	1	4.935	4.46	4.145	3.947	-	View

Technical Specifications

Samtec FHP-13-01-T-S technical specifications.

General

Contact Finish - Mating	TIN
Contact Material	Bronze, Copper
Contact Plating	Tin
Contact Shape	Square
Contact Type	Female Socket
Gender	Receptacle
Housing Color	Black
Insulation Color	Black
Insulation Material	Polymer
Lead Free	Lead Free
Max Operating Temperature	105°C
Min Operating Temperature	-55°C
Mount	Through Hole
Number of Contacts	13
Number of Positions	13
Number of Rows	1
Orientation	Straight
Packaging	Rail/Tube
Pitch	3.96mm
Radiation Hardening	No
Reach SVHC Compliant	No
RoHS Compliant	Yes
Series	FHP
Termination	Solder
