Technical Specifications
Samtec MNT-108-BK-G technical specifications.
General
| Contact Material | Bronze |
| Contact Plating | Gold |
| Depth | 5.08mm |
| Height | 6.1mm |
| Housing Color | Black |
| Length | 20.32mm |
| Max Current Rating | 2A |
| Max Operating Temperature | 90°C |
| Min Operating Temperature | -40°C |
| Max Voltage Rating (AC) | 675V |
| Number of Contacts | 16 |
| Number of Positions | 8 |
| Number of Rows | 1 |
| Orientation | Straight |
| Packaging | Bulk |
| Pitch | 2.54mm |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
Compliance
| RoHS | Compliant |
Datasheet
Samtec MNT-108-BK-G Datasheet
Download the complete datasheet for Samtec MNT-108-BK-G to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
