SAMTEC

SFM-105-01-S-D-A

Datasheet

10 Pos 1.27mm Socket Header, 5A, 250V AC, Gold Plated

Samtec

SFM-105-01-S-D-A

Name: SFM-105-01-S-D-A Samtec
Brand: Samtec
SKU: SFM-105-01-S-D-A

10 Pos 1.27mm Socket Header, 5A, 250V AC, Gold Plated

10-position, 2-row shrouded socket strip with 1.27mm pitch and straight, top-entry orientation. Features gold-plated copper female socket contacts for a 5A current rating and 350V voltage rating. Through-hole mounting with solder termination and a black housing. Operating temperature range of -55°C to 125°C.

Voltage Rating350V

Current Rating5A

MountingThrough Hole

Quick Jump:

Pricing & Availability

Distributor	Package Type	Min Qty	1+	50+	100+	500+	Stock	Action
Samtec	Tube	1	4.174	3.403	2.89	2.568	-	View

Technical Specifications

Samtec SFM-105-01-S-D-A technical specifications.

General

Color	Black
Contact Material	Copper
Contact Plating	Gold
Contact Type	Female Socket
Current Rating	5A
Depth	3.68mm
Gender	Receptacle
Housing Color	Black
Length	9.52mm
Max Operating Temperature	125°C
Min Operating Temperature	-55°C
Max Voltage Rating (AC)	250V
Mount	Through Hole
Number of Contacts	10
Number of Positions	10
Number of Rows	2
Orientation	Straight
Package Quantity	1
Packaging	Rail/Tube
Pitch	1.27mm
Radiation Hardening	No
Reach SVHC Compliant	No
RoHS Compliant	Yes
Row Spacing	0.05inch
Series	Tiger Eye™ SFM
Termination	Solder
Voltage Rating	350V
