10-position, single-row socket strip with a 1.27mm pitch. Features straight, through-hole termination for solder mounting. Contacts are rectangular, forked, and made of bronze with gold plating for mating. The female connector has a black polymer housing and insulation, with a maximum current rating of 1A and an operating temperature range of -55°C to 125°C.
Quick Jump:
Technical Specifications
Samtec SLM-110-01-G-S technical specifications.
General
Contact Finish - Mating
GOLD
Contact Material
Bronze
Contact Plating
Gold
Contact Shape
Rectangular
Contact Type
Forked
Depth
2.54mm
Gender
Female
Housing Color
Black
Insulation Color
Black
Insulation Material
Polymer
Length
12.7mm
Max Current Rating
1A
Max Operating Temperature
125°C
Min Operating Temperature
-55°C
Number of Contacts
10
Number of Positions
10
Number of Rows
1
Orientation
Straight
Packaging
Bulk
Pitch
1.27mm
Radiation Hardening
No
RoHS Compliant
Yes
Series
SLM
Termination
Solder
Compliance
RoHS
Compliant
