Mains power connector featuring a straight, male socket design with 3 contacts and 3 positions. Rated for 6A at 250VAC, this shielded connector includes a fuse holder for 5 x 20mm fuses and a standard filter type with 68nF capacitance. It offers panel mounting with flanges and a solder terminal termination. Operating temperature range is -25°C to 85°C, with a UL94 V-0 flammability rating and IP40 protection. Approvals include cULus and ENEC, with RoHS compliance.
FrequencyN/A
PackageModule
Current6A
Capacitance68nF
Quick Jump:
Technical Specifications
Schurter 4304.4024 technical specifications.
General
Approvals
cULus, ENEC
Capacitance
68nF
Package/Case
Module
Current
6A
Current Rating
6A
Depth
55mm
Features
Shielded
Filter Type
STANDARD
Flammability Rating
UL94 V-0
Fuse
Yes
Fuse Size
5 x 20mm
Gender
Male
Height
65mm
Leakage Current
250uA
Length
50mm
Max Current Rating
6A
Max Operating Temperature
85°C
Min Operating Temperature
-25°C
Max Voltage Rating (AC)
250V
Mount
Panel, Flanges
Number of Contacts
3
Number of Ports
1
Number of Positions
3
Operating Frequency
N/A
Orientation
Straight
Package Quantity
10
Packaging
Bulk
Radiation Hardening
No
Ratings
IP40
Reach SVHC Compliant
No
RoHS Compliant
Yes
Series
FKI
Termination
Faston
Voltage Rating
250V
Voltage Rating (AC)
250V
DC Rated Voltage
250V
Weight
4.585615oz
Width
50mm
Compliance
RoHS
Compliant
Datasheet
Schurter 4304.4024 Datasheet
Download the complete datasheet for Schurter 4304.4024 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
