The 3RF23401AA04 is a single-pole single-throw (SPST) switch designed for industrial automation and control applications. It features a high current rating of 40A and a maximum operating temperature of 60°C. The switch is available in a 460 package and can be mounted on a DIN rail or panel. It has a voltage rating of 460V AC and 230V AC, and is approved for use in various regions including UL, CSA, CE, and GOST. The switch has a termination type of screw and a width of 2.657 inches.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Siemens 3RF23401AA04 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Approvals | UL, CSA, CE, GOST |
| Package/Case | 460 |
| Contact Current Rating | 40A |
| Current Rating | 40A |
| Depth | 156mm |
| Height | 100mm |
| Isolation Voltage | 600V |
| Length | 67.5mm |
| Load Current | 40A |
| Max Operating Temperature | 60°C |
| Min Operating Temperature | -25°C |
| Max Supply Voltage (AC) | 460V |
| Min Supply Voltage (AC) | 230V |
| Max Voltage Rating (AC) | 460V |
| Mount | DIN Rail, Panel |
| Number of Poles | 1 |
| Reach SVHC Compliant | No |
| Termination | Screw |
| Throw Configuration | SPST |
| Voltage Rating (AC) | 460V |
| Width | 2.657inch |
| RoHS | Not Compliant |
