The 6EP1961-3BA01 is a 24V 40A power supply module designed for industrial applications. It operates within a temperature range of 0°C to 60°C and is rated for IP20 protection. The module measures 125mm in height, 72mm in width, and 125mm in length, and weighs 220g. It has a maximum output power of 960W and an efficiency of 97%. The module is mounted on a DIN rail and is suitable for use in fluid power and control systems.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Siemens 6EP1961-3BA01 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | Module |
| Current - Output 1 | 40A |
| Efficiency | 97% |
| Height | 125mm |
| Input Current | 1.1A |
| Length | 125mm |
| Max Operating Temperature | 60°C |
| Min Operating Temperature | 0°C |
| Max Output Current | 40A |
| Max Output Power | 960W |
| Mount | DIN Rail |
| Nominal Output Voltage | 24V |
| Number of Outputs | 1 |
| Ratings | IP20 |
| Reach SVHC Compliant | No |
| Voltage - Output 1 | 24V |
| Weight | 220g |
| Width | 72mm |
| RoHS | Not Compliant |
