Axial fan with 239 CFM airflow, 115VAC voltage rating, and 3200 RPM speed. Features ball bearing type, aluminium material construction, and lead wire termination. Operates within a temperature range of 14°C to 158°C, consuming 27W of power. Dimensions include 171.5mm length, 51mm height, and 151mm depth, with a noise level of 58dBA. RoHS and REACH SVHC compliant.
Frequency50|60 Hz
PackageAxial
Voltage Rating115V
Power27W
Quick Jump:
Technical Specifications
Sunon A1175-HBT.TC.GN technical specifications.
General
Airflow
239CFM
Bearing Type
Ball
Package/Case
Axial
Depth
151mm
Height
51mm
Length
171.5mm
Material
Aluminium
Max Operating Temperature
158°C
Min Operating Temperature
14°C
Max Power Dissipation
27W
Noise
58dBA
Noise Level
51|58 dB
Operating Frequency
50|60 Hz
Packaging
Bulk
Power Consumption
27W
Radiation Hardening
No
Reach SVHC Compliant
Yes
RoHS Compliant
Yes
RPM
3200RPM
Series
A
Termination
Lead Wire
Voltage Rating
115V
Voltage Rating (AC)
115V
Weight
2lb
Width
51mm
Compliance
RoHS
Compliant
Datasheet
Sunon A1175-HBT.TC.GN Datasheet
Download the complete datasheet for Sunon A1175-HBT.TC.GN to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
