Sunon
DP201AT-2122HBL.GN
SUNON DP201AT/2122HBL.GN Axial Fan, Slim, Shaded Pole Motor, High Speed, Ball, DP Series, 240 VAC, 120 mm, 25 mm
Frequency50|60 Hz
PackageAxial
Current Rating90mA
Power18W
Quick Jump:
Technical Specifications
Sunon DP201AT-2122HBL.GN technical specifications.
General
Airflow
80CFM
Bearing Type
Ball
Package/Case
Axial
Current Rating
90mA
Depth
119mm
Flammability Rating
UL94 V-0
Height
25.5mm
Length
119mm
Material
Aluminium
Max Power Dissipation
19W
Noise
48dBA
Noise (dB)
48dB
Noise Level
44|48 dB
Operating Frequency
50|60 Hz
Operating Supply Voltage
240V
Package Quantity
1
Packaging
Bulk
Power Consumption
18W
Reach SVHC Compliant
No
RoHS Compliant
Yes
RPM
2500RPM
Series
DP
Termination
2 Wire Leads
Voltage Rating (AC)
240V
Weight
0.65lb
Width
25.5mm
Compliance
RoHS
Compliant
Datasheet
Sunon DP201AT-2122HBL.GN Datasheet
Download the complete datasheet for Sunon DP201AT-2122HBL.GN to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
