SUNON

KDE0504PFV2.11.MS.A.GN

Datasheet

40x10mm Axial Fan, 5VDC, 5800RPM, 27dBA, 7CFM, VAPO Bearing

Sunon

KDE0504PFV2.11.MS.A.GN

Name: KDE0504PFV2.11.MS.A.GN Sunon
Brand: Sunon
SKU: KDE0504PFV2.11.MS.A.GN

40x10mm Axial Fan, 5VDC, 5800RPM, 27dBA, 7CFM, VAPO Bearing

Axial fan, 40mm height, 10mm width, delivering 7 CFM airflow at 5800 RPM. Features VAPO bearing type and 2 wire leads termination. Operates at 5VDC with a 140mA current rating, consuming 700mW power. Constructed from UL94 V-0 rated plastic, this fan is UL, CE, and TUV approved, with a maximum operating temperature of 158°C.

Frequency5800RPM

PackageAxial

Current Rating140mA

Power700mW

Quick Jump:

Technical Specifications

Sunon KDE0504PFV2.11.MS.A.GN technical specifications.

General

Airflow	7CFM
Approvals	UL, CE, TUV
Bearing Type	VAPO
Package/Case	Axial
Current Rating	140mA
Flammability Rating	UL94 V-0
Height	40mm
Lead Free	Lead Free
Lead Length	300mm
Material	Plastic
Max Operating Temperature	158°C
Min Operating Temperature	14°C
Max Power Dissipation	700mW
Noise	27dBA
Noise Level	27dBA
Package Quantity	200
Packaging	Tray
Power Consumption	700mW
Reach SVHC Compliant	No
RPM	5800RPM
Series	MagLev®
Speed	5800RPM
Termination	2 Wire Leads
DC Rated Voltage	5V
Weight	0.037lb
Width	10mm
