Axial fan, 80mm x 80mm x 25mm, delivers 41 CFM airflow at 3300 RPM. Features VAPO bearing, 230/240 VAC operating voltage, and 50Hz frequency. Constructed with PVC and plastic, this black fan has a 25mm depth and 300mm lead length. Rated at 33dBA noise level and 4.6W power consumption, it is RoHS compliant and UL94 V-0 flammability rated.
Frequency50Hz
PackageAxial
Current Rating225mA
Power4.6W
Quick Jump:
Technical Specifications
Sunon MA2082-HVL.GN technical specifications.
General
Airflow
41CFM
Bearing Type
VAPO
Package/Case
Axial
Color
Black
Current Rating
225mA
Depth
25mm
Flammability Rating
UL94 V-0
Frequency
50Hz
Height
80mm
Lead Length
300mm
Material
PVC, Plastic
Max Power Dissipation
4.6W
Noise
33dBA
Noise (dB)
33dB
Noise Level
32/33dBA
Operating Supply Voltage
240V
Package Quantity
1
Power Consumption
4.6W
Reach SVHC Compliant
No
RoHS Compliant
Yes
RPM
3300RPM
Series
Maglev
Termination
2 Wire Leads
Voltage Rating (AC)
240V
Weight
0.225lb
Width
25mm
Compliance
RoHS
Compliant
Datasheet
Sunon MA2082-HVL.GN Datasheet
Download the complete datasheet for Sunon MA2082-HVL.GN to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
