Ceramic patch chip antenna for RF and wireless applications. Features dual-band operation at 1.57542GHz and 1.602GHz, with a frequency range of 1.574GHz to 1.61GHz. This surface mount component offers 50 Ohm impedance and a VSWR of 2. Constructed from ceramic material, it measures 25.1mm in length and width, with a height of 7.4mm. Lead-free and RoHS compliant.
Frequency1.57542GHz
MountingSurface Mount
Quick Jump:
Technical Specifications
Taoglas AGGP.25F.07.0060A technical specifications.
General
Frequency
1.57542GHz
Height
7.4mm
Impedance
50R
Lead Free
Lead Free
Length
25.1mm
Material
Ceramic
Max Frequency
1.61GHz
Min Frequency
1.574GHz
Mount
Surface Mount
Number of Bands
2
Package Quantity
100
Packaging
Tray
RoHS Compliant
Yes
VSWR
2
Width
25.1mm
Compliance
RoHS
Compliant
Datasheet
Taoglas AGGP.25F.07.0060A Datasheet
Download the complete datasheet for Taoglas AGGP.25F.07.0060A to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
