TE CONNECTIVITY

1241050-2

Datasheet

4 Pos 2.54mm Header HDR, Male Pin, Gold/Pd, 3A, 250V, SMD

TE Connectivity

1241050-2

Name: 1241050-2 TE Connectivity
Brand: TE Connectivity
SKU: 1241050-2

4 Pos 2.54mm Header HDR, Male Pin, Gold/Pd, 3A, 250V, SMD

4-position unshrouded header with a 2.54mm pitch, designed for surface mount (SMD/SMT) termination. Features male pin contacts made of CuZn with gold or gold-palladium mating finish and gold/tin plating. Rated for 3A current and 250V working voltage, operating between -65°C and 105°C. This straight, vertical PCB mount component is supplied in tape and reel packaging.

Voltage Rating250V

Current Rating3A

MountingSurface Mount

Quick Jump:

Technical Specifications

TE Connectivity 1241050-2 technical specifications.

General

Board Standoff	No (Without)
Color	Black
Contact Finish - Mating	Gold or Gold-Palladium
Contact Gender	Male
Contact Material	CuZn
Contact Mating Length	5.8mm
Contact Plating	Gold, Tin
Contact Protection	No (Without)
Contact Shape	Square
Contact Type	Male Pin
Current Rating	3A
ELV	Compliant
Gender	Male
High Speed Serial Data Connector	No
High Temperature Housing	No
Housing Color	Black
Insulation Color	Black
Insulation Material	Polycyclohexylenedimethylene
Keyed	No
Lead Pitch	2.54mm
Mating Alignment	No (Without)
Mating Connector Lock	No (Without)
Max Operating Temperature	105°C
Min Operating Temperature	-65°C
Mount	Surface Mount
Number of Contacts	4
Number of Poles	4
Number of Positions	4
Number of Rows	2
Orientation	Straight
Package Quantity	350
Packaging	Tape and Reel
PCB Mount Retention	Without
PCB Mounting Orientation	Vertical
Pitch	2.54mm
Plating Thickness	0.8um
Radiation Hardening	No
Reach SVHC Compliant	No
RoHS Compliant	Yes
Row Spacing	2.54mm
Selectively Loaded	No (Without)
Series	AMPMODU MOD II
Stabilizers	No (Without)
Strain Relief	No (Without)
Termination	SMD/SMT
Voltage Rating (AC)	250V
Working Voltage	250V
