Technical Specifications
TE Connectivity 140814-2 technical specifications.
General
| Package/Case | Metal |
| Contact Material | Brass, Tin |
| Contact Plating | Tin |
| ELV | Compliant |
| Gender | Male |
| Insulation | Non-Insulated |
| Material | Brass |
| Mating Tab Width | 0.25inch |
| Mount | Chassis, Board |
| Package Quantity | 1000 |
| Packaging | Box |
| Plating | Tin |
| Radiation Hardening | No |
| Reach SVHC Compliant | Unknown |
| RoHS Compliant | Yes |
| Series | Faston |
| Size | 0.8mm |
| Stud Diameter | 0.161inch |
| Tab Length | 0.311inch |
| Tab Thickness | 0.032inch |
| Tab Width | 0.25inch |
| Terminal Material | Brass |
| Termination | Screw |
Compliance
| RoHS | Compliant |
Datasheet
TE Connectivity 140814-2 Datasheet
Download the complete datasheet for TE Connectivity 140814-2 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
