5-position, 1-level terminal block with a 5.08mm pitch. Features a straight, through-hole mount orientation and a 17.5A current rating at 300V AC. Constructed with brass contacts plated in tin, housed in black UL94 V-0 rated plastic. Includes interlock functionality and operates within a -40°C to 105°C temperature range. Suitable for wire gauges from 12AWG to 30AWG.
Voltage300V
Current17.5A
Voltage Rating300V
Current Rating17.5A
Quick Jump:
Technical Specifications
TE Connectivity 1546074-5 technical specifications.
General
Approvals
UL
Closed End
No (Without)
Color
Black
Contact Material
Brass
Contact Plating
Tin
Current
17.5A
Current Rating
17.5A
Depth
12.5mm
ELV
Compliant
Flammability Rating
UL94 V-0
Housing Color
Black
Interlock
Yes (With)
Lead Free
Lead Free
Length
25.4mm
Max Current Rating
17.5A
Max Operating Temperature
105°C
Min Operating Temperature
-40°C
Max Supply Voltage (AC)
300V
Max Voltage Rating (AC)
300V
Mount
Through Hole
Number of Circuits
5
Number of Contacts
5
Number of Levels
1
Number of Poles
5
Number of Positions
5
Number of Positions Per Level
5
Number of Rows
1
Orientation
Straight
Package Quantity
150
Packaging
Box
Pin Length
3.8mm
Pitch
5.08mm
Plating
Brass
Radiation Hardening
No
Reach SVHC Compliant
Unknown
RoHS Compliant
Yes
Screw Flange
No (Without)
Screwless Terminal Block
No (Without)
Series
Buchanan
Side Stackable
No (Without)
Tail Length
0.15inch
Termination
Solder
Voltage
300V
Voltage Rating
300V
Wire Gauge (Max)
30AWG
Wire Gauge (Min)
12AWG
Wire/Cable Gauge
30AWG
Compliance
RoHS
Compliant
